xNOVA 6K | 6500 Watt 48 Volt Off Grid Hybrid Solar Inverter | 550 Volt PV Input | UL Certified
Overview
The NOVA 6K is a reliable off grid hybrid solar inverter designed for residential and commercial solar energy systems. It provides 6500 watts of output power and accepts up to 550 volt PV input. The inverter integrates solar energy, battery management, and generator backup into one compact device.
Benefits
- Provides clean and stable pure sine wave output suitable for sensitive electronics and heavy appliances
- Dynamic RGB LED status bar allows quick system monitoring with customizable colors
- Integrated Wi Fi connectivity enables monitoring and control via a mobile app on Android and iOS
- USB on the go supports external storage for data logging and firmware updates
- Advanced cooling system with dust protection extends device lifespan in harsh environments
- Detachable LCD control panel offers flexible installation and multiple communication ports for battery management system integration
- User configurable settings for input voltage, output timers, charging current, and power source prioritization through the LCD panel
- Smart battery charging system improves battery performance and longevity across different battery types
- Compatible with solar arrays, generator input, and utility mains to maximize uptime
- Built in protections guard against overload, overheating, and short circuits
- Cold start function allows power up even when the battery is fully drained for emergency backup
Features
- Pure sine wave output
- Dynamic RGB LED status bar
- Integrated Wi Fi connectivity with mobile app support
- USB on the go for data logging and firmware updates
- Advanced cooling and dust protection
- Detachable LCD control panel with RS485 CAN BUS and RS232 communication ports
- User configurable settings on LCD panel
- Smart battery charging system
- Flexible power source compatibility including solar generator and utility mains
- Built in overload overheating and short circuit protections
- Cold start capability
Specifications
- Model: RS H6548V5
- Rated Output Power: 6500W
- Parallel Capability: Yes up to 6 units
- Input Voltage: 120 VAC
- Efficiency: Greater than 95 percent at rated resistive load with fully charged battery
- Frequency Range: 50Hz and 60Hz auto detection
- Output Voltage Waveform: Pure sine wave
- Output Voltage Regulation: 120 VAC plus or minus 5 percent
- Peak Efficiency: 91 percent
- Surge Capacity: Two times rated power for five seconds
- Nominal DC Input Voltage: 48 VDC
- Cold Start Voltage: 46.0 VDC
- Battery Voltage: 48 VDC
- Floating Charge Voltage: 54 VDC
- Overcharge Protection: 66 VDC
- Operating Temperature Range: Negative 10 degrees Celsius to 40 degrees Celsius
- Storage Temperature: Negative 15 degrees Celsius to 60 degrees Celsius
- Humidity: 5 percent to 95 percent relative humidity non condensing
- Dimensions (millimeters): 147.4 by 432.5 by 575.6 (620.6 with extension box)
- Net Weight: 18.4 kilograms or 41 pounds
